Masthead Amplifier Kit
Meet the Whyte Masthead WMHA25-4 a high-performance, 4-way UHF masthead amplifier with 25 dB gain and triple filtering for TETRA, 4G and 5G interference.
High Selectivity LTE Rejection
The built-in Class 1, Category D 470–694MHz band-pass filtration helps prevent unwanted interference from 4G/5G LTE and TETRA (Terrestrial Trunked Radio) signals, delivering cleaner and more reliable UHF reception.
Exceeds Radio Equipment Directive (RED)
| Selectivity EN303354 Section 4.5.5 | Class 1 (TFR) |
| Gain Variation EN303354 Section 4.5.1 | <1dB |
| Noise Figure EN303354 4.5.2 | <4dB |
| Amplifier Intermodulation EN303354 4.5.3 | -4dBm (TOI) |
| Return Loss EN303354 4.5.4 Input/Output | >12dB |
| Internal Immunity EN303354 (EN50083-2 4.4.2) | ≥37.8dBc (Min.) |
Unrivalled Selectivity and Gain
variation performance.
Key Technical Specifications
Adjustable Gain
Control
10–25dB UHF gain adjustment with a maximum output level ofa 100dBµV, providing flexible signal amplification for a wide range of installation requirements.
Low Noise Performance
A noise figure of less than 4dB, combined with less than 1dB gain variation, ensures consistent and stable signal performance.
Weather
Proof
The robust casing incorporates integrated water channels, drainage points and run-off surfaces to help protect the amplifier from water ingress and the elements.
Reliable Power
Supply
The 12V DC, 400mA dual RF-output power supply is designed to provide reliable, long-term operation.
Remote
powering
The masthead amplifier can be conveniently powered remotely through any RF output, providing greater flexibility during installation.
Installer Friendy Features
Stay-open lid for easier installation and access
Angled housing
for improved access to
amplifier F-type connectors
Multiple mounting options, including mast
and wall mounting
Compact heavy duty Anti-UV housing
12V DC 400mA Dual power supply
